10 Port PPS and NMEA signal isolated splitter
The PPS3-G10 is a robust 10-port PPS and NMEA splitter that delivers precise, isolated signal distribution for critical timing and communication systems. It offers configurable RS232 or RS422 outputs, LED status indicators, and full galvanic isolation in a compact, rugged design ensuring reliable, interference-free operation in any environment.
10 Port PPS and NMEA signal isolated splitter
The PPS3-G10 is a high-performance 10-port PPS and NMEA signal splitter designed for precision timing and communication applications. It allows a single PPS or NMEA source to be distributed to multiple devices while maintaining full galvanic isolation between all ports and the power supply, ensuring maximum signal integrity and protection against ground loops.
Each output port is independently configurable for RS232 or RS422/RS485, providing flexibility across a wide range of systems without requiring external converters. The PPS input supports adjustable trigger levels, selectable edge triggering, and pulse stretching to guarantee consistent and reliable output pulses.
The PPS3-G10 also functions as an NMEA message splitter, efficiently handling data rates up to 115200 baud and supporting all parity, start, and stop bit settings. With its rugged steel housing, compact 19-inch rack-mountable design, and LED indicators for status monitoring, this splitter is built for durability and ease of operation.
Ideal for environments requiring accurate and synchronized timing signals, the PPS3-G10 ensures minimal delay, consistent performance across all outputs, and dependable operation even in demanding industrial or communication setups.
